| Tension | 10 - 30 V DC |
| Courant mA (24 V) | 250 |
| Niveau de protection | IP 20 |
| Environnement opérationnel | Environnement sec |
| Plage de température (fonctionnement) | 0...50 °C |
| Plage de température (stockage) | -20...+60 °C |
| Humidité | 0…95 % sans condensation |
| Poids | 650 g |
| Dimensions | 124 mm x 48 mm x 124 mm |
| Port LAN | 10/100 MBit/s Voll- und Halbduplexbetrieb, automatische Erkennung Patch-Kabel / Cross-Over-Kabel |
| Port WAN | 10/100 MBit/s Voll- und Halbduplexbetrieb, automatische Erkennung Patch-Kabel / Cross-Over-Kabel |
| VPN | OpenVPN, 1 Tunnel |
| Méthode de chiffrement | Blowfish, AES, DES/3DES |
| Chiffrement algorithme | MD5, SHA1 |
| Autorisation | Pre-Shared-Key, X.509 |
| Firewall | 1:1 NAT, IP-Filter, Port-forwarding, stateful inspektion |
| Services | DHCP-Server, DHCP-Client, DNS-Server, NTP-Client, PPP Server, DynDNS |
| Interface 1 (COM1) | RS-232/485 |
| Interface 2 (COM2) | MPI/PROFIBUS - 12 MBit/s |
| Port USB | USB Host 2.0 |
| Entrées | 4 Stück (Low 0-3,2 V, High 8-30 V) |
| Sorties | 2 Stück 50 mA @ 12 V / 100 mA @ 24 V |
| Agréments | EN 61000-6-4, EN 61000-6-2; Pour plus de détails, voir la Déclaration de conformité sur le portail de téléchargement |
| Pays opérationnels | 240 Pays |
