EH9711-3SFP-DC

9-port Managed IEC61850-3 switch with 3x 100/1000 SFP ports, 24~48VDC

More details...

Availability : 2-3 weeks

EH9711-3SFP-DC

1 132,32 €

11-Port Fast Ethernet IEC 61850-3 Industrial Managed Switch

  • Comprehensive Connectivity
    • 8x FE ports + 3x Gbps SFP ports
    • 1 x RS-232 console port (RJ-45 connector)
    • 4 x DIP switches for Ring control
  • Compact & Robust Enclosure
    • Dimensions (mm): 77 x 167 x 138
    • Operating temp. from -40°C to +75°C
    • Ambient relative humidity from 5% to 95%
  • Secured & Trusted Network
    • Secure industrial network design based on IEC62443
    • Access Control with 802.1x, AAA, ACL, IP Source Guard, etc.
    • Network Monitoring with Port Mirroring, sFlow, etc.
  • Time Precision Certifications
    • IEEE 1588 power profile specific parameters with C37.238 & IEC 61850-9-3
    • Precision time synchronization with SyncE and IEEE1588v2 (PTP) P2P/E2E TC with delay within 50ns.
  • Substation-Fit Certifications
    • IEC 61850-3 & IEEE 1613 compliance
    • CE/FCC/UL & other certifications
  • Reliable & Redundant Topology
    • Low-voltage 24-48 VDC or high-voltage 110-240 VAC/110-300 VDC power input
    • ITU-T G.8032 ERPS Ring, MSTP/RSTP/STP supported
  • type IEC 61850 Gigabit Ethernet
  • temperature -40 ~ 85°C
  • ports 8
  • construction DIN-rail
  • application Smart Grid Ethernet switch
